RISC-V Arithmetic Instructions II: Bitwise Operations

1Learning Outcomes¶

Write assembly to perform bitwise operations.
Understand why there are only three RISC-V bitshift operations: sll, srl, and sra (and their immediate equivalents slli, srli, srai).

🎥 Lecture Video

We recommend reviewing the C Bitwise Operations before continuing.

We have previously discussed that in RISC-V, operations determine “type,” i.e., how register contents are treated (see this table). Next, we will see how this concept applies to RISC-V’s instruction set for bitwise operations.

2Bitwise Operations¶

As before, bitwise operations are performed on n-bit operands one bit at a time.

The RV32I ISA provides instructions for common bitwise operations.^[1]. Table 6 shows that most bitwise operations correspond to two instructions:

RISC-V: Register. Perform the bitwise operation on two register operands rs1 and rs2, and store the result in a destination register rd.
RISC-V: Immediate. Perform the bitwise operation on one register operand rs1 and an immediate imm, and store the result in a destination register rd.

In Table 1 below, hover over each footnote to jump to the corresponding section on this page.

Table 1:RISC-V bitwise arithmetic instructions.

Bitwise Operation	RISC-V: Register	RISC-V: Immediate
AND	`and rd rs1 rs2`	`andi rd rs1 imm`
OR	`or rd rs1 rs2`	`ori rd rs1 imm`
XOR	`xor rd rs1 rs2`	`xori rd rs1 imm`
NOT^[2]	`not rd rs1` (pseudo)
Shift left^[3]	`sll rd rs1 rs2`	`slli rd rs1 imm`
Shift right^[4]	`srl rd rs1 rs2` `sra rd rs1 rs2`	`srli rd rs1 imm` `srai rd rs1 imm`

2.1The `not` pseudoinstruction¶

In RISC-V, bitwise NOT is a pseudoinstruction and corresponds to a bitwise XOR with the immediate -1:

NOT is XOR with -1.

Pseudoinstruction	Name	Description	Translation
`not rd rs1`	bitwise NOT	`R[rd] = ~(R[rs1])`	`xori rd rs1 -1`

Notes:

A bitwise NOT of the value R[rs1] is defined as a bitwise inversion of all 32 bits of register rs1.
Recall from our discussion of XOR properties that for a single bit x, the expression x XOR 1 (x ^ 1) inverts x.
The immediate -1 has 32-bit two’s complement signed integer representation 0b 1111 1111 1111 1111 1111 1111 1111 1111.

These three notes together explain Figure 1 below.

"TODO" — Figure 1:Add immediate instruction in RISC-V and C with negative values.

Show explanation

The source register rs1 has value 0b 1111 1111 1111 1111 1111 1111 1111 0111.
Destination register rd has value 0b 0000 0000 0000 0000 0000 0000 0000 1000.
By definition, this operation is both NOT (a bitwise inversion) and XOR with the 32-bit two’s complement representation of -1.

2.2Shift left¶

Like all RISC-V arithmetic instructions, the left-shift operation sll must write all 32 bits of the destination register. Recall our discussion of the left shift operation: the expression x << n shifts the bits of x left by n bits, filling the n lower bits with zero. The sll operation therefore fills in these new bits with 0.

2.3Shift right¶

Recall our discussion of the right shift operation: the expression x >> n shifts the bits of x right by n bits, filling the n lower bits with zero or one. In C, this was determined by x’s type. In RISC-V, the instruction determines what the lower bits are filled in with

srl, or Shift Right Logical (srli for immediate). “Zero-extend” and fill the upper bits with 0. This instruction effectively interprets register rs1’s contents as an unsigned integer. Read more in an earlier section.
sra, or Shift Right Arithmetic (srai for immediate). Fill in the upper bits with the sign bit of register rs1. This instruction effectively interprets register rs1’s contents as a signedinteger. Read more in an earlier section.

shift arithmetic: signed

3Other RISC-V arithmetic instructions¶

General multiplication is not included in the base RISC-V ISA but is specified as part of common RISC-V extensions. See the mul instruction on the RISC-V green card.

The circuitry for general multiplication is significantly more complicated than the bitwise left- and right-shift operations discussed above. For similar reasons, we do not discuss division, modulo, and floating point operations.^[5]

4Practice¶

Practice

After the below instructions are executed, what is in register x12?

1
2
3
4
li    x10 0x34FF
slli  x12 x10 0x10
srli  x12 x12 0x08
and   x12 x12 x10

A. 0x0
B. 0x3400
C. 0x4F0
D. 0xFF00
E. 0x34FF
F. Something else

Show answer

B. 0x3400.

These instructions are the RISC-V translation of the C practice example when we discussed C bitwise operations. We recommend reviewing that first.

Each line, explained:

Write value 0x000034FF to register x10.
R[x10] << 0x10 is 0x34FF0000. Write this value to register x12.
R[x12] >> 0x8 is 0x0034FF00 because the sign bit of R[x12] is initially 0.
R[x12] & R[x10] is 0x000034FF & 0x0034FF00 is 0x00003400. See Figure 1 from the C practice example.

Footnotes¶

See the full set of arithmetic instructions on the RISC-V green card.
↩
See the not pseudoinstruction.
↩
See shift left.
↩
See shift right.
↩
We encourage you to read the RISC-V unprivileged ISA for the M Extension and the F extension.
↩
